tBOX323-835-FL

tBOX323-835-FL

CPU: Intel® Atom™ E3845, DDR3L-1333, 4GB memory

LxBxH: 244 x 180.5 x 65.1 mm

Category:

Description

Produktblad tbox323-835-fl

Features

  • EN 50155, EN 50121 certified and EN 45545-2 compliance
  • Fanless operation and wide temperature range from -40°C to +70°C (EN 50155 class TX)
  • Intel® Atom™ Bay E3845 4C@1.91GHz
  • DDR3L-1333 4GB memory onboard
  • Isolated RS-232 (4-Wire)/422/485 and DIO
  • Lockable M12 LAN and power connector
  • USB 2.0 and SATA2
  • 24V/110VDC input (optional)
  • Suspension 2.5” SATA HDD and 1 CFast™/mSATA
  • Internal 4 PCIe Mini Card slot and SIM slot

Introduction

The tBOX323-835-FL, a fanless railway PC, is designed for in-train applications. Integrated with onboard quad-core Intel® Atom™ E3845 processor and 4 GB low-powered DDR3L memory. The fanless railway PC boosts its computing performance and specializes its I/O design with five isolated COM ports, two M12-type LAN connectors, USB 2.0 ports, and one isolated digital I/O. The railway PC also provides VGA and HDMI outputs for in-train surveillance. The tBOX323-835-FL is an ideal all-in-one IoT (Internet of Things) solution for various applications, including railway multi-functions of gateway, controller, digital signage management and surveillance. Certificated with EN50155 and EN50121 for rolling stock and complied with EN45545-2 for fire resistance, the rugged embedded system operates reliably in a -40ºC to 70ºC operating temperature range (EN50155 Class TX) and in a high vibration environment.



CPU
  • Intel® Atom™ processor E3845 (4C@1.91GHz)
Chipset
  • SoC integrated
System Memory
  • DDR3L-1333, 4GB memory
BIOS
  • AMI
COM
  • 4 x Isolated RS-232 (4-Wire)/422/485 (terminal)
  • 1 x RS-232 (DB9)
USB
  • 2 x USB 2.0
Ethernet
  • 2 x M12-type GbE LAN
Display
  • 1 x HDMI
  • 1 x VGA
CANbus
  • N/A
Digital I/O
  • 1 x isolated DI/DO (6-IN/2-OUT)
Audio
  • Mic-in/Line-out (screw type)
Storage
  • 1 x 2.5″ SATA HDD (Suspension designed, HDD height support 7/9.5/12.5/15mm)
  • 1 x CFast™/1 x mSATA
Expansion
  • 3 x PCIe Mini card with 2 x SIM slots (two front accessible)
Others
  • 1 x M12-type VDC power input
  • 1 x Reset switch
  • 1 x Remote power switch
  • 4 x Antenna opening
  • 1 x Fuse
Power Supply
  • 12 ~ 32 VDC, typical 24 VDC
  • 77 ~ 137.5 VDC, typical 110 VDC
Power Consumption
  • N/A
Watchdog Timer
  • 255 levels, 0 ~ 255 seconds/minutes
Construction
  • Aluminum extrusion and heavy-duty steel, IP40
Operating Temperature
  • -40°C ~ +70°C (-40°F ~ +158°F) W/T SSD
  • -25°C ~ +55°C (-13°F ~ +131°F) W/T HDD
Relative Humidity
  • 5% ~ 95%, non-condensing
Vibration
  • 3 Grms with SSD & CFast™ (5-500Hz, X, Y, Z direction; Random) (IEC60068-2-34)
  • 2 Grms with HDD (5-500Hz, X, Y, Z direction; Random)
Shock
  • Comply EN 61373 section 10 table 3 category 1 class A and class B up to 5Grms (30ms, ±X/Y/Z direction)
Dimensions
(W x D x H)
  • 244 x 180.5 x 65.1 mm (9.6″ x 7.1″ x 2.56″)
Weight (net/gross)
  • 3 kg (6.61 lb)/ 3.8 kg (8.38 lb)
Certifications
  • CE, EN50155, EN50121, EN45545-2 compliance
EOS
  • Windows® 10, WE8S, WES 7, Linux
Mounting
  • Wall mount
