W24ITWS-MHA2-EX

24 tum, upplösning: 1920×1080, Kontrast: 3000:1, Ljusstyrka: 250

Description

Produktblad W24ITWS-MHA2-EX



KEY FEATURES

  • Intel® 11th Generation Tiger Lake UP3 Core™ i5 CPU HMI Panel PC
  • Signature true flat display screen with edge-to-edge design
  • Aluminum, anti-corrosion treated housing
  • Superior sealing with front IP65 protection against dust and water
  • Projected Capacitive Multi-Touch Screen (PCAP)
  • Fanless Design
  • Support wide range 9-29 V DC input
  • Quick & Easy Removable 2.5” SSD Bay Slot
  • Support PCIe x4 Card
  • Class 1 Division 2, Group A-D, T4 Certification



Display

Size

23.8 inches

Touch / Glass

Projected Capacitive Multi Touch Screen

Resolution

1920×1080

Panel Brightness

250 nits

Contrast Ratio

3000:1

View Angles

89,89,89,89

Active Area

527.04×296.46 mm

System Specification

Processor

Intel® Tiger Lake Core™ i5-1135G7, 2.4 GHz(turbo up to 4.2GHz)

Memory

2 x SODIMM, DDR4 3200 MHz, 4GB 8GB (Optional) 16GB (Optional) 32GB (Optional)

Storage

1 x M.2 2280 NVMe SSD, 64GB up to 512GB 2 x 2.5″ Removable 256GB SSD up to 512GB (Optional)

Ethernet controller

Intel® Ethernet Controller I211-AT + Intel® Ethernet Connection I219-LM

Operating System

Windows 10 IoT Enterprise (Optional)

WLAN

Support (Optional)

BT

Support (Optional)

Expansion Port

Modular Design for easy service in the field

Mechanical

Dimension

603.6 x 373 x 91.4 mm

Cut out

583x353mm

Mounting

Panel mount VESA Mount

Enclosure

Metal Housing

Cooling System

Fanless design

Environment

Operating Humidity

10% to 90% (non-condensing)

Operating Temperature

-20~60°C

Storage Temperature

-40~80°C

Shock

MIL-STD-810G Method 516.6 (Optional)

Vibration

MIL-STD-810G Method 514.6

Altitude

nan

Certification

Certification

CE, FCC Hazardous Location Safety: Class 1, Division 2, Group A, B, C, D

IO Ports

USB Port

4 x USB 3.2 Gen.1 (Type-A)

Serial Port

2 x RS232/422/485 (Default RS232) 1 x RS232

LAN

2 x Giga LAN RJ45 Connector

Video

1 x DP1.4 1 x HDMI 2.0 (Optional)

Audio

1 x Audio Combo Connector (Mic in / Line Out)

Expansion Port

1 x mPCIe slot 1 x PCIe x16 slot (x4 signal) 1 x M.2 2230 Key E slot for WiFi 1 x M.2 2280 Key M slot for NVMe SSD Swappable 2.5” HDD/SSD Bay Slot

Indicator

1 x LED Indicator for storage

Power Input

1 x 9~29V DC, 3-Pin Terminal Block

Control

Button

1 x Power Button with LED Indicator 1 x Reset Button

Accessory

Accessory

100~240V AC to DC Adapter Power Cord Open Wire Cable with terminal block connector Driver CD & Manual Mounting clips VESA screws

Power

Power Rating

9V~29V DC with protection fuse

Adapter

12V 120W
