rBOX201-6COM

Features

• Fanless and cableless design
• Supports AMD LX800 processor
• Wide temperature operation of -40°C ~ +70°C
• 1 isolated DIO (4-IN/4-OUT)
• 6 isolated COM ports
• 2 isolated 10/100Mbps Ethernet ports
• 2 watchdog timer
• LED indicators
• SNMP V1/V2c
• Supports 1 CompactFlash™
• 2 power paths with terminal block and 12-48VDC
• Supports AXView monitoring software package

Introduction

The rBOX201-6COM din-rail fanless embedded system utilizes the low power AMD LX800 processor and is designed to withstand temperatures ranging from -40°C to +70°C for use in extreme operating environments. To prevent ESD and over-voltage, this super compact-size rBOX201-6COM is equipped with six isolated RS-232/422/485, two isolated 10/100Mbps Ethernet and one isolated DIO port for offering magnetic isolation protection. Two power paths input minimizes the risk of data loss in the event of a single power failure. IP30 housing, wide operating temperature range and Safety/EMI/EMS compliance, rBOX201-6COM is ideal for intelligent computing and communication solutions in critical environments such as power utility, transportation and more. Besides, rBOX201-6COM is also specially designed for remote control/ monitoring management applications like unmanned control room, industrial machine, automatic parking lot, traffic cabinet and more. The ready-to-run rBOX201-6COM equipped with AXView monitoring soft ware is a total solution for power plant automation, facility monitoring systems, intelligent transportation systems, and more.
