Description
Produktblad iru152
Features
- RISC-based (i.MX 6UltraLite) processor 528 MHz
- 512MB DDR3 SDRAM onboard
- 8GB eMMC flash onboard
- 2 Mini Card slots (Wi-Fi, 3G/4G or LoRa)
- 4 analog input channels (16-bit, 250 kS/s)
- 1 isolated COM port
- 1 isolated DIO (2-in/2-out)
- Embedded Linux operating system (Yocto)
- Wide operating temperature range from -40°C to +70°C
| CPU | - NXP i.MX 6 UL processor, ARM® Cortex®-A7 @ 528 MHz
|
| Chipset | |
| System Memory | - 1 x DDR3-1600 onboard, 512 MB
|
| COM | - 1 x RS-232/422/485 with isolation 2KV
|
| USB | |
| Ethernet | - 1 x 10/100 Mbps Ethernet with isolation 1.5KV
|
| PoE | |
| CANbus | |
| Digital I/O | - 1 x DIO (2-IN/1-OUT) with Isolation 2KV
|
| Analog Input | - 4 x AI (Isolation)
- Input Type Differential
- Input Range: (Software programmable)
- Unipolar: 0 ~ 10V, 0 ~ 5V
- Bipolar: ±10V, ±5V
- Resolution:16-bit
- Sampling Rate: 10 S/s to 250 kS/s
- FIFO Buffer Size: 2,048 samples
- Overvoltage Protection: ±55V
- Trigger source: Analog or digital
- (software selectable)
|
| Display | |
| Wireless | - 2 x Mini Card slot
- 1 x SIM Card socket
|
| Storage | - 1 x eMMC 8GB flash onboard
|
| Others | - 1 x EEPPROM (2 Kb)
- Console/COM switch
- Device ID setting 0 ~ 255
|
| Power Supply | - 9 – 48 VDC power input range
|
| Watchdog Timer | - 0.5 to 128 sec. with a time resolution of 0.5 sec.
|
| Construction | - Extruded aluminum and heavy-duty steel, IP40
|
| Operating Temperature | - -40°C ~ +70°C (-40°F ~ +158°F)
|
| Relative Humidity | |
| Vibration | - 2 Gms @ (10 ~ 150Hz sine wave; operation)
|
Dimensions
(W x D x H) | - 55 x 82 x 108 mm (2.16″ x 3.23″ x 4.25″)
|
| Weight (net/gross) | - 0.32 kg (0.71 lb)/0.53 kg (1.17 lb)
|
| Certifications | - FCC Part 15
- Heavy Industrial CE
|
| EOS | - OS: Yocto 1.8.1 (Fido)
- Kernel: 3.14.52
|
| Mounting | |
