Kompakt industriell PC

CPU: Intel 4th generation i7/i5, 2 x SODIMM , Max 16GB DDR3L 1333/1600 MHz

Graphics: Intel HD Graphic 4600, LxBxH: 264 x 57 x 192 mm



Produktblad IH70SB7-111


• Intel 4th Generation Core i7/i5 processor (Haswell)
• Flexible storage devices, One 2.5-inch HDD and One SSD socket
• Multiple I/Os, Three Serial Ports and Six USB Ports
• Supports +12V DC-IN Power input

System Specification

Processor Intel 4th generation i7/i5 processor(Haswell)
System Chipset Intel® 8 series Chipset (QM87)
System Memory 2 x SODIMM , Max 16GB DDR3L 1333/1600 ÌÇz
Graphic Chipset Intel HD Graphic 4600
Supports DirectX 11 and OpenGL 4.0
Ethernet Controller Intel I210IT Gigabit-LAN Controller+ I218LM Gigabit-LAN PHY
I/O Chipset FINTEK F81867
Serial 3 x RS232(1xOptional), 1 x RS232/422/485* port
USB 4 x 3.0 , 2 x USB 2.0
Expansion Slot 1 x Mini PCle Slot (for Full size module)
1 x Mini PCle Slot (for half size Wifi module)
1 x PCle (x16) slot 1 x PCle (x4) slot
SDD Interface 1 x mSATA SSD slot

I/O Connectors

Front Side I/O
  • 2 x USB Type-A Receptacle
  • 1 x Power/HDD LED
  • 1 x Power Reset Button
  • 1 x Power on Button
Back Side I/O
  • 2 x RJ-45(10/100/1000 Mbps)
  • 2 x PS/2
  • 1 x VGA 25P DSUB (male)
  • 3 x RS232)(1xOptional)1x RS232/422/485
  • 4 x USB 3.0
Power input +12V DC IN (Lockable, Power Jack)

Mechanical and Environment

Dimensions (L x W) 264 x 57 x 192 mm (W x H x D)
Color S:Silver
Construction Aluminum housing

Audio Specification

Audio Controller Realtek ALC886 HD codec (Line-in, Line out, Mic-in)

Mechanical & Environment Specification

Operating Temperature 0~50℃
Operating Humidity 5% ~ 95% RÇ (non-condensing)
Mounting Desktop/wall-mounting

Product Spec

OS Windows 10 IoT Enterprise
  • Note: All Specifications are subject to change without prior notice!
    *If you use SBC on-board RS485, you need to set appropriate state of RTS line before sending/receiving data in your software program.We offer additional board that can perform auto-direction hardware function.
