Description
Features
- Design for Industrial Automation, M2M application
- Onboard Atom Dual Core D2550 1.86 GHz Processor
- 1 x DDR3 SODIMM, max. 4GB
- 3 x RS422/485 communication with isolation protection
- Support 8 GPIO by Phoenix type Terminal Block
- 2x Giga LAN, 2x USB, 1x VGA, 1x Line in, Line out, Micro In
- Fanless, High efficiency thermal design w/ sealed construction
- 1.5KV DC power isolation resistance
System Specification
| Processor | Intel® Atom Dual Core D2550 1.86 GHz |
| BIOS | AMI 4Mbit Flash |
| System Chipset | Intel® NM10 |
| System Memory | 1 x SODIMM, Max 4GB DDR3 800(2GB Default) |
| Graphic Interface | Integrated in Intel NM10, LVDS/CRT |
| Ethernet Controller | Dual Broadcom BCM57780 GbE controller |
| USB | 4 x USB 2.0 by pin-header(internal) ; 2 x USB 2.0 (external) |
| NAND Flash | 1 * 32GB mSATA SSD |
I/O Connectors
| Front Side I/O | 1 x power Button 1 x Micro in , Line out , Line in Jack 3 x Isolated RS422/485 auto-detected with Indicator 8 x GPIO by Phoenix type Terminal Block |
| Back Side I/O | 1 x 3 pin Power Input w/ Phoenix type Terminal Block 1 x Power Switch On / Off 2 x RJ-45 (Giga LAN) 1 x VGA 1 x RS232 2 x USB |
Mechanical and Environment
| Dimensions (L x W) | 296mm x 169mm x 66mm |
| Construction | Aluminum housing |
| Power Input | +24V DC In with 1.5KV DC Isolation Resistance(+9~36V DC Input Acceptable) |
| Net Weight (kg) (without touch) | 0.0 |
| Gross Weight (kg) (single packing) | 0.0 |
Ethernet Specification
| Ethernet Controller | Dual Broadcom BCM57780 GbE controller |
Mechanical & Environment Specification
| Operating Temperature | -15 to 55 deg.C |
| Operating Humidity | 5% to 95% (non condensing) |
| Mounting | VESA/Wall-mount/Desktop |
| Anti-Vibration | 5Hz~500Hz /1Grms /3 Axis |
| Anti Shock | 15G, 11ms duration |
- *The weight information is for reference purpose.The actual weight will vary according to then options you choose,for example,the touch/glass option.
- Note: All Specifications are subject to change without prior notice!
