eBOX530-840-FL

eBOX530-840-FL

Fläktlös Box PC

CPU: Intel® Atom™ E3825, 1 x 204-pin SO-DIMM DDR3L-1066/1333, up to 8 GB

LxBxH: 132 x 95.4 x 47.5 mm

Category:

Description

Produktblad ebox530-840-fl

Features

  • Intel® Atom™ E3825 1.33 GHz dual core
  • Fanless operation design with full feature I/O
  • 204-pin DDR3L-1333/1600 SO-DIMM, up to 8GB
  • 2 COM ports, 1 GbE LAN and 1 Mini PCIe slot
  • Supports one AT/ATX mode quick switch
  • Supports Jumbo Frame (9k), WoL, PXE Remote Boot

Introduction

The palm- size eBOX530-840-FL embedded system powered by Intel® Atom™ dual core processor E3825 (codename: Bay Trail) comes with DDR3L memory maximum capacity up to 8 GB and one full-size PCI Express Mini Card with mSATA supported. The eBOX530-840-FL is built of heavy-duty aluminum extrusion with IP40 anti-dust ingress protection giving to it a high degree of structural strength. Its fanless design and excellent thermal solution allows it to operate noiseless and properly at temperature ranging from -20°C to +60°C in extremely critical environments. The rugged embedded box computer is an ideal fit to various embedded applications such as transportation, POS, kiosk, industrial control automation and medical equipment.



CPU
  • Intel® Atom™ processor E3825 1.33 GHz onboard
Chipset
  • SoC Integrated
System Memory
  • 1 x 204-pin SO-DIMM DDR3L-1066/1333, up to 8 GB
BIOS
  • AMI
COM
  • 2 x RS-232/422/485
USB
  • 4 x USB 2.0
Ethernet
  • 1 x 10/100/1000 Mbps (Intel® i210IT)
Display
  • 1 x HDMI or 1 x VGA
Digital I/O
  • N/A
Audio
  • MIC_in/Line_out
Storage
  • 1 x 2.5” SATA HDD bay (max. height 9.5mm)
  • 1 x mSATA
Expansion
  • 1 x Full-size PCI Express Mini Card slot with mSATA (PCI Express + USB signal)
Others
  • 1 x VDC 12V power input connector
  • 1 x AT/ATX switch
  • 2 x SMA type connector opening for antenna
Power Supply
  • Input: AC100~240V, AC 36W adapter with lock
  • Output: +12VDC@3A
Watchdog Timer
  • 255 levels, 1 ~ 255 sec.
Construction
  • Aluminum extrusion and heavy-duty steel, IP40
Operating Temperature
  • -20°C ~ +60°C (-4°F ~ +140°F) (with W.T. HDD, DRAM)
Relative Humidity
  • 10% ~ 90%, non-condensing
Vibration
  • 3 Grms with SSD (5-500 Hz, X, Y, Z directions)
Dimensions
(W x D x H)
  • 132 x 95.4 x 47.5 mm (5.19″ x 3.75″ x 1.87″)
Weight (net/gross)
  • 0.5 kg (1.1 lb)/ 0.6 kg (1.32 lb)
Certifications
  • CE
EOS Support
  • WES7, WE8S
Mounting
  • Wall mount
  • DIN-rail
  • VESA mount





Kategori: Datorer, Box PC
