Description
Features
- 6th Generation Intel® Xeon E3, 7th Generation Core™ i7/i5/i3 Processors
- HD 4K resolution & 4U Height Design
- Flexibility, Connectivity and Multi-Expansion
- High Storage Density & Easy Maintenance
- 9-36V wide voltage and -15 to +55°C wide temperature
System Specification
| Processor | Intel® Core™ i7-7700T, 2.9 GHz~3.8 GHz Intel® Core™ i5-7500T, 2.7 GHz~3.3 GHz Intel® Core™ i3-7100T, 3.4 GHz Intel® Xeon® E3-1268L v5, 2.4 GHz~3.4 GHz |
| BIOS | Insyde BIOS |
| System Chipset | Intel® C236 PCH |
| System Memory | 2 x Slots DDR4 2400 MHz, Default w/o ECC (up to 32GB option) |
| Graphic Chipset | Intel® HD Graphics P630/630 |
| SATA | 2 x External 2.5” SATA 3.0 (6Gb/s) 2 x Internal 2.5” SATA 3.0 (6Gb/s) Support RAID 0/1/5/10 |
| Expansion Slot | SKU1: 1 PCIe 3.0 x16, 1 PCIe 3.0 x4 1 PCI SKU2: 1 PCIe 3.0 x8, 1 PCIe 3.0 x4, 1 PCI Expansion I/O module (Preliminary) |
| Operating System | Windows 10 IoT Enterprise (64bit) |
| Storage | 2 x Swappable 2.5” SATA 3.0 (6Gb/s) 2 x On board 2.5” SATA 3.0 (6Gb/s) Support RAID 0/1/5/10 |
Internal I/O
| USB | 2 x USB 2.0 Pin header, 1 x USB 3.0 type A |
| Serial Port | 2 x COM ports (RS-232/422/485) w/Isolation D-Sub 9, switch by SW (RS-232/422/485) |
| PS/2 | 1 x PS/2 pin header |
| Parallel Port | 1 x LPT port pin header |
| Mini PCIE | 2 x Mini PCIe socket (Full size) |
| USIM | 1 x USIM slot |
Mechanical and Environment
| Dimensions (L x W) | 195 (W) x 177 (H) x 225 (D) mm |
| Net Weight (kg) (without touch) | 5.23kg (excl. PCIe card, storage, RAM etc.) |
Audio Specification
| Codec | Audio Codec ALC283 |
| Connectors | Line Out, Mic in (3.5 mm Jack) |
Mechanical & Environment Specification
| Operating Temperature | 0~40° C (32 ~ 104°F)(with HDD) 0~50° C (32 ~ 122°F)(with SSD /CFast) -15~55° C (-5~131° F)(with Industrial SSD) |
| Certifications | CE / FCC |
| Mounting | Panel Mount (Optional), Table Mount (Optional), Rack Mount (Optional) |
| Power consumption | Max : 50W (w/o external I/O and PCI/ PCIe Cards) |
| Storage Temperature | -20~60° C (-4~140° F)(excl. HDD/SDD/CFast) |
Power Management
| Power Input | 9V to 36V DC-in , 4-Pin Terminal Block/DC Jack , Max : 220W (Either one) |
Output Video I/O
| VGA | 1 x VGA, 1920 x 1200 @60 Hz D-Sub 15pin |
| DP | 2 x Display Ports 1.2, up to 4096×2304@60Hz,Female connector w/ with lock |
| Active three display | VGA + DP + DP |
External I/O
| USB | 6 x USB3.0,USB Type A (1A/5W) |
| Serial Port | 2 x COM ports (RS-232/422/485) w/Isolation D-Sub 9, switch by SW (RS-232/422/485) |
| Ethernet | 3 x Giga LAN RJ45 Connector (2 x intel I210 and 1 x I219 PHY) intel iAMT 11.0, Wake On LAN |
DI/DO
| Digital input | 8ch dry contact DI0~DI7, 1.5kV Isolation Logic1: open;logic 0: dose to GND |
| Digital output | 8ch DO0~DO7, 1.5kV Isolation 200mA max/channel by internal com 12V or 5V |
| WDT | Watch Dog Timer supported |
Others
| LED indicator | 4 x HDD, 1 x WLAN/WWAN |
| Button | 1 x Power Button w/ LED, 1 x Clear CMOS Button, 1 x Reset Button |
