K-TEK-M76-HP-3

76.0mm x 32.6mm, IP67, 3 keys rugged silicone rubber force Sensing Resistor pointing device

Category:

Description

MEDICAL: lab, hospital, clinic, dental, such as carts, diagnostic equipments, operation rooms, dialysis centers etc;
MATERIAL HANDLING: mobile keyboard, data entry, assembly line etc
MILITARY: Army, Navy, Air force
INDUSTRIAL: Industrial automation, pharmaceutical, oil and gas, food and beverage, clean or dirty manufacturing environments, warehouses

OTHER INDUSTRIES

MAIN FEATURES:
Wearable and anti-tearance silicone coat designed for extreme climatic conditions like chemical corrosion, dust,  dirt, oil etc. It contains antibiotic constituents which is anti-bacterial for clean environment such as hospital, laboratory.

Waterproof execution according to IP67 protection from top silicone cover for waterproof /dirtproof / wetherproof and easy cleaning, with mounting holes on the edge for easy tightly mounting to enclosure or panel.

USB/PS2 connection cables that plug directly into computer like normal mouse operations.


MECHANICAL DATA

Key: 3 keys + 1 Hula Point button
Key top style: One silicone coat with rubber keys with very good tactile feeling.
Switch life: more than 10 million of operations.
Cable Length: 2.0m or customized cable
G.W.: 0.035KGs
Dimensions: 76.0mm x 32.6mm x 8.6mm (front panel)

ELECTRICAL DATA
Supply Voltage: +5V DC +/-5%
Current Rating: 15mA

Power: 1.0W
Lifespan> 3 years
Switch Contact Material: Carbon-on-Gold key switch technology with gold PCB.
Interface: USB/PS2.
OS: All Windows, Linux, Unix, Mac OSX, Vxworks, Android, (U-cos–To be confirmed)

ENVIRONMENTAL ADAPTABILITY
Operating temperature:-25°C to +60°C

Storage temperature: -30°C to +70°C
Humidity: 100%
Atmospheric pressure: 60-106Kpa

RELIABILITY
RoHS, CE and FCC, ESD
Protection Level: IP67, NEMA 6P
Key Lifespan >10 million actuations
MTBF >50000H
MTTR <30min

WARRANTY: 1 year
