eBOX626-842-FL

Fläktlös Box PC

CPU: Intel® Celeron® J1900, 1 x 204-pin SO-DIMM DDR3L-1066/1333, up to 8GB

LxBxH: 200 x 120 x 46 mm

Category:

Description

Produktblad ebox626-842-fl

Features

  • Intel® Atom™ E3826 1.46 GHz dual-core or Intel® Celeron® J1900 2.0 GHz quad-core SoC
  • 204-pin DDR3L-1066/1333 SO-DIMM, up to 8GB
  • Fanless operation design with full feature I/O
  • 2 RS-232/422/485, 1 RS-232 and 4 USB 2.0 ports
  • One 2.5” SATA drive bay and mSATA supported
  • 2 PCI Express Mini Card slots and 1 SIM slot
  • VGA and HDMI with dual-view supported
  • 10-34 VDC wide range DC input

Introduction

The eBOX626-842-FL is the energy-efficient fanless embedded box PC suited for rugged and extreme applications with its extended temperature and wide range voltage capability. The extreme compact box PC utilizes an onboard Intel® Celeron® quad core processor J1900 2.0GHz (codename: Bay Trail-D) to boast both excellent performance and ultra-low power consumption. The ultra-slim fanless embedded computer supports system memory up to 8 GB with one DDR3L-1066/1333 SO-DIMM socket and offers HDMI and VGA display outputs, offering not only high computing capability but also excellent graphics performance. Integrated single-chip design, the brand new ruggedized embedded system is lighter and thinner compared to previous eBOX620 series. Supporting wide operating temperature between -20°C to +55°C and 10~34VDC wide DC input voltage, the fanless embedded PC is excellence for wide range of industrial applications. Its passive cooling design also offers quiet, fanless operation with low power consumption, and all at an attractive price point. With full-featured of I/O interfaces, the Intel® Celeron®-based eBOX626-842-FL supports two RS-232/422/485 ports, one RS-232 port, VGA, HDMI, audio, dual Gigabit Ethernet LAN ports, four high-speed USB 2.0, three SMA type connector openings for antenna, 10~34VDC power input connector, and one ATX power switch. One 2.5″ SATA HDD drive bay and mSATA are also embedded in the embedded computer to possess sufficient storage.



CPU
  • Intel® Celeron® J1900 2.0GHz
Chipset
  • SoC integrated
System Memory
  • 1 x 204-pin SO-DIMM DDR3L-1066/1333, up to 8GB
BIOS
  • AMI
COM
  • 2 x RS-232/422/485
  • 1 x RS-232
USB
  • 4 x USB 2.0
Ethernet
  • 2 x 10/100/1000 Mbps (Intel® i211AT)
Display
  • 1 x VGA
  • 1 x HDMI
Digital I/O
  • N/A
Audio
  • Mic-in/Line-out
Storage
  • 1 x 2.5” SATA HDD
  • 1 x mSATA
Expansion
  • 1 x Full-size PCI Express Mini Card slot (USB + PCI Express signal)
  • 1 x Half-size PCI Express Mini Card slot (USB + PCI Express signal)
  • 1 x SIM slot
Others
  • 3 x SMA type connector opening for antenna
Power Supply
  • 42.5 W, 10~34VDC
Watchdog Timer
  • 255 levels, 1 ~ 255 sec.
Construction
  • Aluminum extrusion and heavy-duty steel, IP40
Operating Temperature
  • -20°C ~ +55°C (with J1900, W.T. SSD & DRAM/ CAPA842)
Relative Humidity
  • 10% ~ 90% , non-condensing
Vibration
  • 3 Grms w/ SSD (5-500Hz, X, Y, Z directions)
Dimensions
(W x D x H)
  • 200 x 120 x 46 mm (7.87” x 4.72″ x 1.81″)
Weight (net/gross)
  • 1.1kg (2.43lb)/ 1.8kg (3.97lb)
Certifications
  • CE
EOS Support
  • WES8, WES7
Mounting
  • Wall mount
  • DIN-rail
  • VESA mount
