eBOX565-500-FL

Fläktlös Box PC

CPU: Intel® Core™ i5-6300U/i3-6100U or Celeron® 3955U, 1 x 260-pin SO-DIMM DDR4-2133, up to 16GB

LxBxH: 141.6 x 106 x 73 mm

Description

Produktblad ebox565-500-fl

Features

  • Intel® Core™ i5-6300U 2.4 GHz/i3-6100U 2.3 GHz/Celeron® 3955U 2.0 GHz (Skylake ULT SoC)
  • 260-pin DDR4-2133 SO-DIMM, up to 16GB
  • Compact size with 9~36 VDC wide range input
  • 2 HDMI, 2 COM and 4 USB 3.0 ports
  • Supports Jumbo Frame (9.5K), WoL, PXE and Teaming

Introduction

The eBOX565-500-FL is designed to support the 6th generation Intel® Core™ i5-6300U or Celeron® 3955U processor with one 260-pin DDR4-2133 SO-DIMM socket with up to 16GB system memory. The eBOX565-500-FL is designed for reliable use in industrial environments with an IP40-rated enclosure, a wide range 9 to 36 VDC power input, a wide temperature ranges from -10°C to 50°C (14°F to 122°F), as well as up to 3G vibration endurance. To fulfill various needs, the palm-sized industrial embedded computer, which measures 141.6 x 106 x 73 mm in size, provides rich I/O connectivity including two HDMI ports, one RS-232/422/485 port, one RS-232 port, four USB 3.0 ports, two Gigabit Ethernet ports, and two SMA type connector openings for antenna. One PCI Express Mini Card slot enables the addition of Wi-Fi, 3G, or LTE wireless cards.



CPU
  • Intel® Core™ i5-6300U 2.4 GHz/i3-6100U 2.3 GHz/Celeron® 3955U 2.0 GHz,
Chipset
  • SoC integrated
System Memory
  • 1 x 260-pin SO-DIMM DDR4-2133, up to 16GB
BIOS
  • AMI
COM
  • 1 x RS-232/422/485
  • 1 x RS-232
USB
  • 4 x USB 3.0
Ethernet
  • 2 x 10/100/1000 Mbps (Intel® i210AT, i218)
Display
  • 2 x HDMI
Digital I/O
  • N/A
Audio
  • N/A
Storage
  • 1 x 2.5” SATA HDD drive bay
  • 1 x mSATA
Expansion
  • 1 x Full-size PCI Express Mini Card (USB + PCI Express signal)
Others
  • 2 x SMA type connector opening for antenna
  • 1 x AT/ATX quick switch
  • 1 x ATX power switch
  • 1 x Reset button
Power Supply
  • 9 – 36 VDC
Watchdog Timer
  • 255 levels, 1 ~ 255 sec.
Construction
  • Aluminum extrusion and heavy-duty steel, IP40
Operating Temperature
  • -10°C ~ +50°C (+14°F~+122°F) (with W.T. SSD)
Relative Humidity
  • 10% ~ 95%, non-condensing
Vibration
  • 3 Grms with SSD (5-500Hz, X, Y, Z directions)
Dimensions
(W x D x H)
  • 141.6 x 106 x 73 mm (5.57″ x 4.17″ x 2.87″)
Weight (net/gross)
  • 1.074 kg (1.76 lb)/1.67 kg (3.68 lb)
Certifications
  • CE
EOS Support
  • Win 10 IoT, Win 8.1, Linux
Mounting
  • Wall mount
  • Din-rail
  • VESA mount
