EACIL22S

CPU: Intel® Apollo Lake N3350, 1.1 GHz, Minne: 4GB LPDDR3 1866 MHz

Graphics: Intel® HD Graphics, LxBxH: 100 x 90 x 31 mm

Description

Produktblad EACIL22S

Features
  • Intel® Apollo Lake N3350, 1.1 GHz
  • USB Type-C Connector with Alt Mode: Display Port A/V output, USB data, Power Delivery
  • Compact size 100 x 90 x 31 mm
  • Fanless cooling system
  • Various mounting options: desk, wall, VESA
  • Suitable for smart factory and outdoor applications



System Specification

ProcessorIntel® Apollo Lake N3350, 1.1 GHz
BIOSInsyde UEFI
System Memory4GB LPDDR3 1866 MHz
Graphic InterfaceIntel® HD Graphics
Watchdog TimerProgrammable 256 levels, timer interval 1 to 255 sec.
StorageeMMC: Onboard 64 GB
Optional mSATA: up to 1TB SSD

Mechanical and Environment

Dimensions (L x W)100 x 90 x 31 mm
ColorMetal Housing
Cooling FansFanless
Power InputTerminal Block / 2 Pin
Power source range9V to 36V DC
Net Weight (kg) (without touch)0.8 kg
MountingDesk Mounting (Default), Wall Mounting (Default),
VESA Mounting (Optional)

Mechanical & Environment Specification

Operating Temperature-20° C to +65° C
Operating Humidity10~90% RH (non-condensing)
CertificationsCE / FCC
Storage Temperature-25° C to +70°C

Product Spec

OSWindows® 10 IoT Enterprise
Linux
Ubuntu

Ordering Information

Optional
  • WLAN External Antenna
  • VESA Mounting Kit

Packing List

Standard Packing List
  • Quick Start Guide
  • Driver CD

External I/O

USB2 x USB Type-A 2.0
1 x USB Type-C [Alt Mode] :
– Display Port A/V output
– USB data
– Power Delivery up to 15W(5V/3A)
Ethernet2 x Giga LAN





Kategori: Datorer, Internet of Things
